Network Message Chart
BCM Network Input Messages
Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
Vehicle speed | PCM | The BCM uses the vehicle speed data for the autolock and auto-unlock features. |
RKE data | RTM | Provides the BCM with the lock/unlock status of the driver door latch. The lock/unlock status is used for the illumination of the door lock status indicator. |
Source reference 1360
