Pin | Circuit | Gauge | Qualifier |
|---|---|---|---|
A1 | CPK19 (BU) | 26 | 14A005 |
A1 | CPK19 (BU-GN) | 22 | 14631 |
A2 | CPK23 (YE) | 26 | 14A005 |
A2 | CPK23 (YE-VT) | 22 | 14631 |
A3 | * | * | 14A005 |
A4 | * | * | 14A005 |
A5 | CPW25 (YE-BU) | 22 | 14A005 |
