Vehicle applicability: This diagnostic supplement covers multiple Ford vehicles and engines. Follow the application named in the source below. Some references apply to vehicles other than Mustang.
Reference Values 6-49
1.6L GTDI Escape / Kuga
1.6L GTDI Escape / Kuga
198 Pin PCM
Typical Diagnostic Reference Values
Inputs Component/PID Measured/PID Values Units Only Measured/PID KOEO Hot Idle 48 KM/H (30 89 KM/H (55 MPH) MPH) AAT AAT Sensor 66.20 59 42.80 42.80 DEG C (DEG F) AAT_V AAT Sensor 3 3.23 3.68 3.68 VOLTS AC_REQ PID NO NO NO NO YES/NO APP PID 0 0 16 18 % APP_ PID 0 0 0 0 DEG MAXDIFF APP_MODE PID NO PEDAL NO PEDAL PART PEDAL PART PEDAL NO PEDAL/ PART PEDAL APP1 APP Sensor 0.76 0.76 1.49 1.71 VOLTS APP1 APP Sensor 14.90 14.90 30.19 34.11 % (APP_D) APP2 APP Sensor 0.38 0.38 0.75 0.86 VOLTS APP2 APP Sensor 7.45 7.45 15.29 17.25 % (APP_E) B+ PID 12.12 14.38 14 14.02 VOLTS BARO PID 3.94/98.94 3.94/98.94 3.94/99.97 3.94/98.94 VOLTS/kPa (14.35)/156.11 (14.35)/156.11 (14.50)/157.02 (14.35)/156.11 (PSI)/Hz/ /397.44 /397.44 /401.46 /397.44 in-H O 2 BOO1 BPP Switch OFF OFF OFF OFF ON/OFF BOO2 BPP Switch OFF OFF OFF OFF ON/OFF BRKOVR_ PID 4 4 4 4 NUMERIC ACTION VALUE BRKOVRD_ PID 105 105 106 106 NUMERIC POSS VALUE CAC_T CACT Sensor 25 (77) 23 (73.40) 19 (66.20) 12 (53.60) DEG C (DEG F) CAC_V CACT Sensor 2.86 2.94 3.10 3.38 VOLTS DECHOKE PID YES NO NO NO YES/NO
Original table alignment retained · Scroll horizontally if needed
2016 Powertrain Control/Emissions Diagnosis, Gasoline Engines, 3/2015
Source reference 5403
