Connector End View C1698 - Camshaft Position Bank 1 Sensor 1 (Cmp11)

OEM Connector End Views

Source configuration appliesSource reference 4,247HTML edition

← Chapter contents Manual collection

Connector End View C1698 - Camshaft Position Bank 1 Sensor 1 (Cmp11) — original illustration 1, reference 4247Original colors & callouts · Select to enlarge

Vehicle Uses

Sensor - Fuel Rail Pressure

CONNECTOR VIEWS > CONNECTOR END VIEW C1698 - CAMSHAFT POSITION BANK

1 SENSOR 1 (CMP11)

Connector:C1698

Description

CAMSHAFT POSITION BANK 1 SENSOR 1 (CMP11)

Color

DK GY

Harness

12C508

Base Part #

part# N/A

Service Pigtail

See Below
