Rear Quarter Window Glass Adjustment - Convertible

501-11 Glass, Frames and Mechanisms

2016 MustangReference 1,279 / 6,619HTML edition

← Chapter contents Procedure contents

9. Open the door.

Rear Quarter Window Glass Adjustment - Convertible — original illustration 1, reference 1279Original colors & callouts · Select to enlarge

10. Adjust the rear quarter window glass as necessary.

1. Loosen the rear quarter window glass bolts.

2. Adjust the rear quarter window glass as necessary.

Rear Quarter Window Glass Adjustment - Convertible — original illustration 2, reference 1279Original colors & callouts · Select to enlarge

11. Close the door.
