19 | — | Camshaft bearing cap (part of 6049) (2 required) |
20 | 6K254 | Secondary tensioner (2 required) |
21 | — | Camshaft bearing cap (part of 6049) (16 required) |
22 | 6K297 | Secondary tensioner shoe (2 required) |
23 | 6250 | LH intake camshaft |
24 | 6268 | Secondary timing chain (2 required) |
25 | 6256 | Intake camshaft Variable Camshaft Timing (VCT) (2 required) |
26 | 6256 | Exhaust camshaft Variable Camshaft Timing (VCT) (2 required) |
27 | 6250 | LH exhaust camshaft |
Engine — Lower Components
Source reference 148
