Exhaust Manifold RH — 2016 workshop reference 263

Exhaust Manifold RH — original illustration 1, reference 263Original colors & callouts · Select to enlarge

6-Speed Automatic Transmission - 6R80/6-Speed Manual Transmission - MT82

15. Install the battery heat shield and fasteners. Torque : 80 lb.in (9 Nm)

Exhaust Manifold RH — original illustration 2, reference 263Original colors & callouts · Select to enlarge

16. Install the cowl extension and fasteners. Torque : 26 lb.ft (35 Nm)

Source reference 263

2016 Mustang workshop publication supplied to Mustang Atlas. Original technical text and illustrations; HTML formatting by Mustang Atlas. Source page numbering is retained for traceability. Follow the configuration, revision, warnings, and cross-references in the material. About this edition.
