Brake Caliper

206-04 Rear Disc Brake 2016 Mustang

Removal and Installation Procedure revision date: 02/11/2015

Base Part Number: 2B302

Removal

NOTICE: If the fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water.

NOTE: Removal steps in this procedure may contain installation details.

1. Remove wheel and tire. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).

2. Loosen the parking brake cable adjustment nut.

Brake Caliper — original illustration 1, reference 2840Original colors & callouts · Select to enlarge

Step 3

1. Disconnect the parking brake cable from the lever.

2. Detach the parking brake cable from the bracket and position aside the parking brake cable.

Source reference 2840
