Oil Pan — 2016 workshop reference 298

Oil Pan — original illustration 1, reference 298Original colors & callouts · Select to enlarge

7. Remove the oil level indicator.

Oil Pan — original illustration 2, reference 298Original colors & callouts · Select to enlarge

8. Remove the retainers and the radiator top shield.
