With security pack
7. NOTE: This step is only necessary when installing a new component.
Remove the steering column lock module. Refer to: Steering Column Lock Module (211-05 Steering Wheel and Column Electrical Components, Removal and Installation).
Installation
NOTICE: DO NOT hammer, pry or force steering column and column shafts during installation or removal. Failure to follow this instruction may cause damage to steering components that could lead to loss of steering control during vehicle operation and could result in serious personal injury or death.
1. To install, reverse the removal procedure.
2. NOTE: This step is only necessary when installing a new component.
With the steering system fully assembled, remove the anti-rotation pin and the spindle bolt.
