Ambient Air Temperature Sensor

412-00 Climate Control System - General Information 2016 Mustang

Removal and Installation Procedure revision date: 01/22/2015

Base Part Number: 12A647

Removal

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

2. Remove the underbody shield.

Ambient Air Temperature Sensor — original illustration 1, reference 3693Original colors & callouts · Select to enlarge

Step 3

1. Remove the ambient air temperature sensor.

2. Disconnect the ambient temperature sensor connector.

Source reference 3693
