Receiver Drier - 5.2L 32V Ti-VCT — 2016 workshop reference 3816

412-00 Climate Control System - General Information 2016 Mustang

Removal and Installation Procedure revision date: 07/31/2015

Receiver Drier - 5.2L 32V Ti-VCT

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. Recover the refrigerant. Refer to: Air Conditioning (A/C) System Recovery, Evacuation and Charging (412-00 Climate Control System - General Information, General Procedures).

2. With the vehicle in NEUTRAL, position it on a hoist. Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

3. Remove the bolts and the underbody shield.

Receiver Drier - 5.2L 32V Ti-VCT — original illustration 1, reference 3816Original colors & callouts · Select to enlarge

4. Remove the bolts and the underbody shield.

Source reference 3816
