Hood Turn Signal Indicator Lamp

417-01 Exterior Lighting 2016 Mustang

Removal and Installation Procedure revision date: 08/7/2015

Removal

1. Remove the pushpins and the hood insulation panel.

Hood Turn Signal Indicator Lamp — original illustration 1, reference 5785Original colors & callouts · Select to enlarge

2. NOTE: LH hood mounted turn signal lamp shown, RH is similar.

Remove the hood mounted turn signal lamp.

1. Disconnect the hood mounted turn signal lamp electrical connector.

2. Remove the screws.

3. Release the tabs.

Source reference 5785
