Parcel Shelf - Coupe — 2016 workshop reference 874

501-05 Interior Trim and Ornamentation 2016 Mustang

Removal and Installation Procedure revision date: 04/23/2015

Parcel Shelf - Coupe

Removal

1. Release the second row seat base floor backrest latch and position the seat backrest in the full flat position.

Parcel Shelf - Coupe — original illustration 1, reference 874Original colors & callouts · Select to enlarge

2. On both sides, remove the loadspace trim panels. Refer to: Loadspace Trim Panel - Coupe (501-05 Interior Trim and Ornamentation, Removal and Installation).

3. NOTE: RH side shown, LH side similar.

On both sides. Release the clips, disconnect the tether clip and remove the D-pillar trim panel.
