Connector End View C412 - Rear Lamp Assembly LH

OEM Connector End Views

Source configuration appliesSource reference 3,938HTML edition

← Chapter contents Manual collection

CU2Z-14S411-ZA

WPT-1288

Gauge:

Connector End View C412 - Rear Lamp Assembly LH — original illustration 1, reference 3938Original colors & callouts · Select to enlarge

16

Pin material:

Silver

Cavities:

4

Vehicle Uses:

Sensor - Catalyst Monitor

Sensor - O2 (HEGO/ EGO)

CONNECTOR VIEWS > CONNECTOR END VIEW C412 - REAR LAMP ASSEMBLY LH

Connector:C412

Description

REAR LAMP ASSEMBLY LH

Color

Harness

14A005

Base Part #

part# N/A

Service Pigtail

See Below

Ford_Mustang_all_2015-2017.pdf · source reference 3938
