Service Pigtail
Check for Terminal Part Numbers
Pin | Circuit | Gauge | Circuit Function | Qualifier |
|---|---|---|---|---|
1 | CBP23 (BN-YE) | 22 | FUSE - 23 OR CIRCUIT BREAKER | |
2 | * | * | Not Used | |
3 | * | * | Not Used | |
4 | GD214 (BK-BU) | 22 | GROUND - INSTRUMENT PANEL STRUCTURE | |
5 | * | * | Not Used | |
6 | * | * | Not Used | |
7 | * | * | Not Used |
