Connector End View C2436 - Footwell Air Discharge Temperature Sensor LH

OEM Connector End Views

Source configuration appliesSource reference 4,346HTML edition

← Chapter contents Manual collection

Service Part Number:

3U2Z-14S411-XHA

Gauge:

Pigtail Kit Part Number

20 WPT-582

Pin material:

Connector End View C2436 - Footwell Air Discharge Temperature Sensor LH — original illustration 1, reference 4346Original colors & callouts · Select to enlarge

Tin

Cavities:

4

Vehicle Uses

Lamp - Dome/Map

Lamp - Map

Lamp - Overhead Console

Module - Warning Chime/ Beltminder

Monitor - Video/DVD

Sensor - EATC In Car Temperature

CONNECTOR VIEWS > CONNECTOR END VIEW C2436 - FOOTWELL AIR

DISCHARGE TEMPERATURE SENSOR LH

Connector:C2436

Description

FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR LH

Color

Harness

14401

Base Part #

part# N/A

Service Pigtail

See Below
