Fuel Tank Filler Pipe — Installation — Fuel Tank And Lines - 2.3L EcoBoost (231kW & 314PS) · Reference 6203

1. Disconnect the vapor tube Quick Release Coupling. Refer to: QUICK RELEASE COUPLING - 2.3L EcoBoost (231kW/314PS).

2. Remove retainers and the Fuel Tank Filler Pipe.

Torque

: 18 lb.ft (25 Nm)

Fuel Tank Filler Pipe — original illustration 1, reference 6203Original colors & callouts · Select to enlarge

REMOVAL AND INSTALLATION > FUEL TANK FILLER PIPE > INSTALLATION

1. To install, reverse the removal procedure.
