Door Latch Lubrication

501-14 Handles, Locks, Latches and Entry Systems 2016 Mustang

General Procedures Procedure revision date: 01/22/2015

Special Tool(s) / General Equipment

Flat-Bladed Screwdriver

Materials

Name	Specification
Motorcraft® Multi-Purpose Grease Spray XL-5-A	ESB-M1C93-B

Activation

NOTE: Typical left front door shown, others similar.

1. Open the door.

Door Latch Lubrication — original illustration 1, reference 1421Original colors & callouts · Select to enlarge

2. Using a flat blade screwdriver, fully close the latch (2 clicks). Use the General Equipment: Flat-Bladed Screwdriver

Source reference 1421
