33. Depower the SRS. Refer to: Supplemental Restraint System (SRS) Depowering (501-20B Supplemental Restraint System, General Procedures).
34. Remove the safety belt anchor, buckle, retractor or inflator. Refer to the appropriate procedure in the safety belt system section.
35. If the safety belt anchor, buckle, retractor or inflator does not have a hard-wired pigtail, cut each of the wires near the electrical connector that connects to the vehicle wire harness.
36. When deploying a safety belt buckle pretensioner, install a nut and bolt of sufficient length and the same diameter used to retain it to the seat.
37. Remove any sheathing (if present) and strip the insulation from the ends of the cut wires.
38. Make a jumper harness to deploy the safety belt anchor, buckle, retractor or inflator by obtaining 2
wires (20 gauge minimum) at least 9.14 m (30 ft). At one end of the jumper harness, connect the wires together.
39. NOTE: Typical safety belt retractor pretensioner shown, other safety belt anchor pretensioners, buckle pretensioners, load-limiting retractors and safety belt inflators similar.
Using the end of the jumper harness where the wires are not connected together, attach each wire of the jumper harness to each wire of the safety belt anchor, buckle, retractor or inflator. Use tape or other insulating material to make sure the leads do not make contact with each other.
