Rear Lower Arm — 2016 workshop reference 2465

Rear Lower Arm — original illustration 1, reference 2465Original colors & callouts · Select to enlarge

3. Support the suspension at curb height. Use the General Equipment: Vehicle/Axle Stands

Rear Lower Arm — original illustration 2, reference 2465Original colors & callouts · Select to enlarge

4. NOTICE: Tighten the suspension bushing fasteners with the suspension loaded or with the weight

of the vehicle resting on the wheels and tires, otherwise incorrect clamp load and bushing damage may occur.

Tighten the rear lower arm-to-frame bolt. Torque : 184 lb.ft (250 Nm)

Source reference 2465
