2. NOTICE: The groove on the 3rd/4th gear synchronizer assembly must be facing away from 4th
gear or damage to the synchronizer assembly can occur.
NOTICE: The 6 synchronizer ring tabs must engage into the 6 gear slot and the 3 synchronizer ring tabs must engage into the 3 synchronizer assembly slots or damage to the synchronizer assembly and synchronizer ring assembly can occur.
NOTE: The 4th gear synchronizer ring assembly outer ring has one identification notch.
With the groove on the 3rd/4th gear synchronizer assembly sleeve facing away from the 4th gear install the 4th gear synchronizer ring assembly and the 4th gear.
Align the 6 synchronizer ring tabs with the 6 gear slots and the 3 synchronizer ring tabs with the 3 synchronizer assembly slots.
