417-01 Exterior Lighting 2016 Mustang

Removal and Installation Procedure revision date: 11/6/2015

Front Fog Lamp

Removal

NOTE: Removal steps in this procedure may contain installation details.

NOTE: Halogen fog lamp shown, LED fog lamp similar.

1. Raise the vehicle on a hoist. Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

2. Remove the push pins, screws and the lower air deflector.

Front Fog Lamp — original illustration 1, reference 5763Original colors & callouts · Select to enlarge

3. Disconnect the front fog lamp electrical connector.

Source reference 5763
