Reversing Lamp - Vehicles With: SVT Performance Package

417-01 Exterior Lighting

2016 MustangReference 5,803 / 6,619HTML edition

← Chapter contents Procedure contents

Reversing Lamp - Vehicles With: SVT Performance Package — original illustration 1, reference 5803Original colors & callouts · Select to enlarge

6. Release the tabs and remove the rear bumper reinforcement.

Reversing Lamp - Vehicles With: SVT Performance Package — original illustration 2, reference 5803Original colors & callouts · Select to enlarge

7. Remove the screws and the reversing lamp assembly. Torque : 15 lb.in (1.7 Nm)

Source reference 5803
