Pin | Circuit | Gauge | Circuit Function | Qualifier |
|---|---|---|---|---|
1 | GD123 (BK-GY) | 16 | GROUND - FENDER FRONT RIGHT | |
2 | CRH04 (VT-GN) | 14 | CTRL MOD. - RELAY HORN |
Available Pigtail Kits
Service Part Number:
3U2Z-14S411-BXAB
Gauge:
16
Pin material:
Silver
Pigtail Kit Part Number
Cavities:
WPT-984
2
Vehicle Uses
A/C Compressor Clutch
EGR Cooler Outlet
Electronic Locking Differential
Horn
Lamp - CHMSL (Center High Mount Stop Lamp)
Lamp - Rear Park
Lamp - Reverse
Lamp - Side Marker
Motor - Adjustable Pedal
Sensor - Adjustable Pedal
Sensor - Brake Fluid Level
Sensor - Cam Shaft Position
Sensor - Cylinder Head Temperature
