Connector End View C498 - Rear Lamp Assembly LH — OEM Connector End Views · Reference 3966

16

Pin material:

Silver

Cavities:

Connector End View C498 - Rear Lamp Assembly LH — original illustration 1, reference 3966Original colors & callouts · Select to enlarge

3

Vehicle Uses

Lamp - Front Cornering/Turn

Lamp - Front Park

Lamp - Front Turn

Lamp - Front Turn/ Marker

Lamp - Headlamp - High/Low Beam

Lamp - Park/Turn

Lamp - Park/Turn/Stop

Lamp - Rear Park

Lamp - Reverse

Lamp - Stop

CONNECTOR VIEWS > CONNECTOR END VIEW C498 - REAR LAMP ASSEMBLY LH

Connector:C498

Description

REAR LAMP ASSEMBLY LH

Color

LT GY

Harness

14A005

Base Part #

part# N/A

Service Pigtail

See Below
