Connector End View C1042 - Side Turn Signal Lamp RH

OEM Connector End Views

Source configuration appliesSource reference 4,060HTML edition

← Chapter contents Manual collection

Connector End View C1042 - Side Turn Signal Lamp RH — original illustration 1, reference 4060Original colors & callouts · Select to enlarge

16

Vehicle Uses

Lamp - Headlamp - High/Low Beam

Module - Heated Seat (driver)

Module - Transfer Case Shift Control

CONNECTOR VIEWS > CONNECTOR END VIEW C1042 - SIDE TURN SIGNAL LAMP

RH

Connector:C1042

Description

SIDE TURN SIGNAL LAMP RH

Color

Harness

14290

Base Part #

part# N/A

Service Pigtail

See Below
