Check for Terminal Part Numbers
Pin | Circuit | Gauge | Circuit Function | Qualifier |
|---|---|---|---|---|
1 | CLF05 (BU-GN) | 20 | CTRL MOD. - BEAM LOW RIGHT | |
2 | * | * | Not Used | |
3 | CBB68 (GY-VT) | 20 | FUSE - 68 OR CIRCUIT BREAKER | |
4 | * | * | Not Used | |
5 | CLS30 (VT-WH) | 22 | RELAY - PARK LAMP | |
6 | * | * | Not Used |
