Connector End View C1110 - Air Conditioning (Ac) Compressor Control Solenoid

OEM Connector End Views

Source configuration appliesSource reference 4,086HTML edition

← Chapter contents Manual collection

Connector End View C1110 - Air Conditioning (Ac) Compressor Control Solenoid — original illustration 1, reference 4086Original colors & callouts · Select to enlarge

Cavities:

3

Vehicle Uses

Sensor - Cam Shaft Position

Sensor - Crank Shaft Position

Sensor - Fuel Tank Pressure Transducer

Sensor - Turbine Shaft Speed

Switch - Fuel Delivery Pressure

CONNECTOR VIEWS > CONNECTOR END VIEW C1110 - AIR CONDITIONING (AC)

COMPRESSOR CONTROL SOLENOID

Connector:C1110

Description

AIR CONDITIONING (AC) COMPRESSOR CONTROL SOLENOID

Color

Harness

14B060

Base Part #

part# N/A

Service Pigtail

See Below
