Connector End View C1127 - Front Side Marker Lamp LH

OEM Connector End Views

Source configuration appliesSource reference 4,092HTML edition

← Chapter contents Manual collection

LH

Connector:C1127

Description

FRONT SIDE MARKER LAMP LH

Color

Harness

14290

Base Part #

part# N/A

Service Pigtail

See Below

Connector End View C1127 - Front Side Marker Lamp LH — original illustration 1, reference 4092Original colors & callouts · Select to enlarge

Check for Terminal Part Numbers

Pin	Circuit	Gauge	Circuit Function	Qualifier
1	GD123 (BK-GY)	20	GROUND - FENDER FRONT RIGHT
