Connector End View C1142 - Fuel Injector 2

OEM Connector End Views

Source configuration appliesSource reference 4,097HTML edition

← Chapter contents Manual collection

Service Part Number:

Pigtail Kit Part Number CU2Z-14S411-ARA

WPT-1302 Gauge:

Connector End View C1142 - Fuel Injector 2 — original illustration 1, reference 4097Original colors & callouts · Select to enlarge

16

Pin material:

Silver

Cavities:

2

Vehicle Uses

Fuel Injector

Pump - Fuel Injection

Solenoid - Fuel Volume Regulator Control

CONNECTOR VIEWS > CONNECTOR END VIEW C1142 - FUEL INJECTOR 2

Connector:C1142

Description

FUEL INJECTOR 2

Color

Harness

14B485

Base Part #

part# N/A

Service Pigtail

See Below
