Connector End View C1650 - Turbocharger Bypass Valve ( T Cby)

OEM Connector End Views

Source configuration appliesSource reference 4,233HTML edition
← Chapter contentsManual collection
Connector End View C1650 - Turbocharger Bypass Valve ( T Cby) — original illustration 1, reference 4233Original colors & callouts · Select to enlarge

Vehicle Uses

Lamp - Headlamp - High/Low Beam

CONNECTOR VIEWS > CONNECTOR END VIEW C1650 - TURBOCHARGER BYPASS

VALVE (TCBY)

Connector:C1650

Description

TURBOCHARGER BYPASS VALVE (TCBY)

Color

LT GY

Harness

12C508

Base Part #

9U465

Service Pigtail

See Below

Ford_Mustang_all_2015-2017.pdf · source reference 4233
