Connector End View C3035 - Front Seat Cushion Blower Motor LH

OEM Connector End Views

Source configuration appliesSource reference 4,363HTML edition

← Chapter contents Manual collection

Available Pigtail Kits

Service Part Number:

3U2Z-14S411-BCB

Gauge:

Pigtail Kit Part Number

16 WPT-1128

Pin material:

Connector End View C3035 - Front Seat Cushion Blower Motor LH — original illustration 1, reference 4363Original colors & callouts · Select to enlarge

Silver

Cavities:

8

Vehicle Uses

Actuator - Door Lock - Decklid/Liftgate

Mirror - Sideview

Solenoid - Brake Shift Park Interlock

Switch - Headlamp

Switch - Power Window - Quarter Glass

Switch - Sliding Door Contact

CONNECTOR VIEWS > CONNECTOR END VIEW C3035 - FRONT SEAT CUSHION

BLOWER MOTOR LH

Connector:C3035

Description

FRONT SEAT CUSHION BLOWER MOTOR LH

Color

LT GY

Harness

14D231

Base Part #

part# N/A
