Connector End View C3312 - Audio Input Socket

OEM Connector End Views

Source configuration appliesSource reference 4,409HTML edition

← Chapter contents Manual collection

Connector End View C3312 - Audio Input Socket — original illustration 1, reference 4409Original colors & callouts · Select to enlarge

10 20

Pin material:

Tin

Cavities:

5

Vehicle Uses

Relay - Flasher

CONNECTOR VIEWS > CONNECTOR END VIEW C3312 - AUDIO INPUT SOCKET

Connector:C3312

Description

AUDIO INPUT SOCKET

Color

Harness

14401

Base Part #

part# N/A

Service Pigtail

See Below
