Oil Pump — Installation

Engine - 2.3L EcoBoost (231kW & 314PS)

Source configuration appliesSource reference 4,740HTML edition
← Chapter contentsManual collection
Oil Pump — original illustration 1, reference 4740Original colors & callouts · Select to enlarge

17. Install the oil pan bolts.

Torque

: 35 lb.ft (48 Nm)

Oil Pump — original illustration 2, reference 4740Original colors & callouts · Select to enlarge

6-Speed Automatic Transmission - 6R80

18. Position the transmission cooling tube bracket and install the nut.

Torque

: 124 lb.in (14 Nm)
