Engine — Engine - 3.7L Duratec (227kW & 301PS) · Reference 5302

: Motorcraft® Silicone Gasket Remover / ZC-30-A

Material

: Metal Brake Parts Cleaner (U.S.) / PM-4-A, PM-4-B (U.S.)

Material

: Motorcraft® Metal Surface Prep / ZC-31-B

Engine — original illustration 1, reference 5302Original colors & callouts · Select to enlarge

NOTE: Rotate the crankshaft in a clockwise direction only.

75. Rotate the crankshaft clockwise and align the timing marks on the intake VCT units as shown in illustration.

Engine — original illustration 2, reference 5302Original colors & callouts · Select to enlarge

76. Remove the bolts and the LH oil tube.
