Front Seat Backrest Cover — 2016 workshop reference 1128

Front Seat Backrest Cover — original illustration 1, reference 1128Original colors & callouts · Select to enlarge

7. Remove the backrest cover insert.

1. Release the pin-type retainers.

2. Position the backrest cover upwards.

Front Seat Backrest Cover — original illustration 2, reference 1128Original colors & callouts · Select to enlarge

8. Position the front seat backrest cover.

1. Release the J-clip.

2. Position the backrest cover from between the seat cushion and backrest cushion.
