Convertible Top Tension Cable — 2016 workshop reference 1635

Convertible Top Tension Cable — original illustration 1, reference 1635Original colors & callouts · Select to enlarge

8. On both sides, disconnect the convertible top material from the front underside of the convertible top front panel.

1. Pull the convertible top material backward and down to release from the convertible top front panel clips.

2. Pull the convertible top material from the double sided tape securing the material to the convertible top front panel.

3. Roll the convertible top material forward and up over the convertible top front panel.

Convertible Top Tension Cable — original illustration 2, reference 1635Original colors & callouts · Select to enlarge

9. Fold the front of the convertible top material back to the first crossbow to expose the tension cable end and stay pad rivets.

Source reference 1635
