Exhaust Manifold RH

303-01C Engine - 5.0L 32V Ti-VCT/5.0L Ti-VCT V8 (308kW/418PS) 2016 Mustang

Removal and Installation Procedure revision date: 05/18/2015

Base Part Number: 9431

Special Tool(s) / General Equipment

Exhaust Manifold RH — original illustration 1, reference 247Original colors & callouts · Select to enlarge	303-050 (T70P-6000) Lifting Bracket, Engine
Exhaust Manifold RH — original illustration 2, reference 247Original colors & callouts · Select to enlarge	303-F072 Support Bar, Engine

Removal

6-Speed Automatic Transmission - 6R80/6-Speed Manual Transmission - MT82

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

2. Recover the refrigerant. Refer to: Air Conditioning (A/C) System Recovery, Evacuation and Charging (412-00 Climate Control System - General Information, General Procedures).

3. Disconnect the battery ground and positive cables. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

4. If equipped with a strut tower cross brace, detach the wiring harness retainer. Remove the nuts and the strut tower cross brace.

Exhaust Manifold RH — original illustration 3, reference 247Original colors & callouts · Select to enlarge

5. NOTE: The engine appearance cover rubber grommets may remain on the cover. If so, remove the grommets from the cover and install them on the intake manifold before installing the cover.

Remove the engine appearance cover.

Source reference 247
