Drive Pinion — 2016 workshop reference 2730

Drive Pinion — original illustration 1, reference 2730Original colors & callouts · Select to enlarge

8. Remove the special tool. Use Special Service Tool: 205-111 (T76P-4020-A11) Adapter for 205-S127 Pinion Depth Gauge.

Drive Pinion — original illustration 2, reference 2730Original colors & callouts · Select to enlarge

9. Remove the special tools. Use Special Service Tool: 205-110 (T76P-4020-A10) Adapter for 205-S127. , 205-160 (T80T-4020-F43) Adapter for 205-S156 Pinion Depth Gauge. , 205-937 Adapter, Pinion Aligning. , 205-1014 Gauge Disc.
