206-04 Rear Disc Brake 2016 Mustang

Removal and Installation Procedure revision date: 08/20/2015

Brake Disc - Vehicles With: SVT Performance Package

Base Part Number: 1125

Removal

NOTICE: Do not allow the brake caliper to hang from the brake hose or damage to the brake hose may occur.

NOTE: Removal steps in this procedure may contain installation details.

1. Remove wheel and tire. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).

2. Disconnect parking brake cable from parking brake shoe actuation lever

Brake Disc - Vehicles With: SVT Performance Package — original illustration 1, reference 2855Original colors & callouts · Select to enlarge

3. Press inward on the tabs and detach the parking brake cable from the bracket.
