96. NOTICE: Do not use metal scrapers, wire brushes, power abrasive discs or other abrasive means

to clean the sealing surfaces. These tools cause scratches and gouges which make leak paths.

Make sure that the mating faces are clean and free of foreign material.

Engine — original illustration 1, reference 456Original colors & callouts · Select to enlarge

97. Remove the bolts and the crankshaft rear seal retainer plate.
