Fender — 2016 workshop reference 809

Fender — original illustration 1, reference 809Original colors & callouts · Select to enlarge

11. Remove the sound insulation.

Fender — original illustration 2, reference 809Original colors & callouts · Select to enlarge

12. Remove the bolts and the fender. Torque : 106 lb.in (12 Nm)

Source reference 809
