Front Door Alignment — 2016 workshop reference 817

Front Door Alignment — original illustration 1, reference 817Original colors & callouts · Select to enlarge

3. Loosen the nuts to permit movement of the door. Loosen: : 2 turn(s)

Front Door Alignment — original illustration 2, reference 817Original colors & callouts · Select to enlarge

4. Adjust the door to specification.

Refer to: Body and Frame (501-26 Body Repairs - Vehicle Specific Information and Tolerance Checks, Description and Operation).

Source reference 817
