Connector End View C1645 - Generator Current Sensor

OEM Connector End Views

Source configuration appliesSource reference 4,229HTML edition

← Chapter contents Manual collection

Connector End View C1645 - Generator Current Sensor — original illustration 1, reference 4229Original colors & callouts · Select to enlarge

Cavities:

3

Vehicle Uses

Coil - Ignition

Sensor - Fuel Low Pressure

CONNECTOR VIEWS > CONNECTOR END VIEW C1645 - GENERATOR CURRENT

SENSOR

Connector:C1645

Description

GENERATOR CURRENT SENSOR

Color

Harness

14290

Base Part #

part# N/A

Service Pigtail

See Below

Ford_Mustang_all_2015-2017.pdf · source reference 4229

Original technical text and illustrations, formatted as HTML. Follow the engine, transmission, equipment, model and year specified in the source. Import and layout checks do not establish applicability to every 2015–2017 Mustang. About this collection.
