Connector End View C2040 - Accelerator Pedal Position (App) Sensor

OEM Connector End Views

Source configuration appliesSource reference 4,263HTML edition

← Chapter contents Manual collection

Pigtail Kit Part Number Service Part Number:

WPT-1381 EU2Z-14S411-EA

Connector End View C2040 - Accelerator Pedal Position (App) Sensor — original illustration 1, reference 4263Original colors & callouts · Select to enlarge

Gauge:

18

Pin material:

Silver

Cavities:

4

Vehicle Uses

Sensor - Catalyst Monitor

CONNECTOR VIEWS > CONNECTOR END VIEW C2040 - ACCELERATOR PEDAL

POSITION (APP) SENSOR

Connector:C2040

Description

ACCELERATOR PEDAL POSITION (APP) SENSOR

Color

Harness

14290

Base Part #

part# N/A

Service Pigtail

See Below
