Connector End View C2066 - Blower Motor — OEM Connector End Views · Reference 4265

Available Pigtail Kits

Service Part Number:

9U2Z-14S411-BB

Gauge:

20

Pigtail Kit Part Number

Pin material:

WPT-1338

Silver

Connector End View C2066 - Blower Motor — original illustration 1, reference 4265Original colors & callouts · Select to enlarge

Cavities:

6

Vehicle Uses

Actuator - Door Lock - LH - Front

Actuator - Door Lock - LH - Rear

Actuator - Door Lock - RH - Front

Actuator - Door Lock - RH - Rear

Module - Occupant Classification

Sensor - Acceleration Pedal Position

Sensor - Transmission Range

Switch - Door Ajar / Interior Lamp

CONNECTOR VIEWS > CONNECTOR END VIEW C2066 - BLOWER MOTOR

Connector:C2066

Description

BLOWER MOTOR

Color

Harness

18B574

Base Part #
