Description
Color
BK
Harness
13412
Base Part #
part# N/A
Service Pigtail
See Below
Check for Terminal Part Numbers
Pin | Circuit | Gauge | Circuit Function | Qualifier |
|---|---|---|---|---|
1 | GD301 (BK-BU) | 22 | GROUND - PILLAR C OR QUARTER PANEL LEFT # 3RD POINT | |
2 | CLS30 (VT-WH) | 22 | RELAY - PARK LAMP |
Available Pigtail Kits
