Oil Pan — Engine - 2.3L EcoBoost (231kW & 314PS) · Reference 4679

Oil Pan — original illustration 1, reference 4679Original colors & callouts · Select to enlarge

10. Install the engine appearance cover and the nuts.

Torque

: 80 lb.in (9 Nm)

Oil Pan — original illustration 2, reference 4679Original colors & callouts · Select to enlarge

REMOVAL AND INSTALLATION > OIL PAN

Special Tool(s) / General Equipment

Oil Pan — original illustration 3, reference 4679Original colors & callouts · Select to enlarge	303-050 (T70P-6000) Lifting Bracket, Engine
