Oil Pan — Installation

Engine - 2.3L EcoBoost (231kW & 314PS)

Source configuration appliesSource reference 4,703HTML edition
← Chapter contentsManual collection
Oil Pan — original illustration 1, reference 4703Original colors & callouts · Select to enlarge

NOTE: Automatic transmission shown in illustration, manual transmission similar.

10. Install the oil pan bolts.

Torque

: 35 lb.ft (48 Nm)

Oil Pan — original illustration 2, reference 4703Original colors & callouts · Select to enlarge

6-Speed Automatic Transmission - 6R80

11. Position the transmission cooling tube bracket and install the nut.

Torque

: 124 lb.in (14 Nm)

Ford_Mustang_all_2015-2017.pdf · source reference 4703

Original technical text and illustrations, formatted as HTML. Follow the engine, transmission, equipment, model and year specified in the source. Import and layout checks do not establish applicability to every 2015–2017 Mustang. About this collection.
